Bronze Ferrule Saddle /Ferrule Strap with Pushfit

Basic Info

Model NO.	P02030
HS Code	8481804090

Product Description

Product Introduction
The Gunmetal standard swivel ferrule saddles provide a quick, permanent, leak free service connection. Consisting of a flat boss strap, bottom strap and ferrule. With an inner plug for valve isolation and a 360° swivel outlet, the ferrule provides service connections dry, wet or under pressure directly into cast iron, ductile iron and steel mains. Asbestos cement, PE and PVC mains can also be tapped via a flat boss strap.
Product Specification

Components NO. Description Material 1. Ferrule UNS C83600 2. Plug UNS C83600 3. Cap UNS C83600 4. Stem UNS C83600 5. Banjo UNS C83600 6. O ring NBR 7. Top strap / Top saddle UNS C83600 8. Stainless steel bolt 316 9. M12 Stainless steel nut 316 10. Bottom strap / Bottom saddle UNS C83600

Ferrule and strap dimensions chat T ID 1 ID 2 3/4" 100mm 25mm 3/4" 100mm 32mm 1-1/2" 100mm 50mm 1-1/2" 100mm 63mm 3/4" 150mm 25mm 3/4" 150mm 32mm 1-1/2" 150mm 50mm 1-1/2" 150mm 63mm 3-4" 200mm 25mm 3/4" 200mm 32mm 1-1/2" 200mm 50mm 1-1/2" 200mm 63mm 3/4" 300mm 25mm 3/4" 300mm 32mm 1-1/2" 300mm 50mm 1-1/2" 300mm 63mm

Accessory
* Leak free NBR O-ring
* Excellent corrosion resistant Stainless steel bolts and nuts.
Installation Instruction
* Fit the top strap on the main, and ensuring the sealing ring is correctly positioned.* Locate the bottom strap with bolts and nuts provided. Make sure the straps sit squarely on the main.* Connect the service pipe to the banjo.* Ensure the cap is tightened down on the banjo and then wind the plug back to seal in the cap.* Install the outlet pipe through banjo. The connection is now made.
Service Condition

Ferrule strap can provide years of service in any trench condition, wet or dry. Even the most aggressive soil conditions.

Safety

It is important to take adequate safety precautions such as the use of protective clothing like gloves, overalls, eye protection and safety footwear during installation.
